不銹鋼儲酒罐一般選擇托耳支撐，即在夾套部位上端焊有托耳型的支撐方式，屬懸空式支撐，這樣與其它設備如冷凝器、管道、儲罐等配套使用，選擇托耳支撐的要有操作臺，操作臺的設計是根據反應釜的尺寸，用槽鋼、圓管等組合而成，根據工藝的所配套的其它設備也就便于安裝操作。
Stainless steel wine storage tank generally adopts lug support, that is, the upper end of the jacket is welded with lug type support, which belongs to suspended support. In this way, it can be used with other equipment such as condenser, pipeline, storage tank, etc. the supporting lug should have an operating platform. The design of the operating platform is based on the size of the reaction kettle, combined with channel steel, circular pipe, etc., according to the process matching other The equipment is easy to install and operate.
如果是單體使用反應釜，一般選擇支腿支撐，即在不銹鋼儲酒罐底部的夾套部位含有三根或四根腿型的支撐，屬落地式支撐，尤其是小的不銹鋼儲酒罐一般容積在500L以下的，選擇這種支撐方式不用焊接操作臺，放置、移動比較方便，但非常重要的一點就是要確定支腿的長度，換言之即底閥到地面的度，支腿的長度一般是在500mm左右，但要根據您的具體使用情況如怎樣接料用什么樣的容器接料等來確定您所需要的長度。
If a single reactor is used, the support legs are generally selected, that is, there are three or four leg supports in the jacket part at the bottom of the stainless steel wine storage tank, which belongs to the floor type support. Especially for the small stainless steel wine storage tank with the volume below 500L, it is not necessary to weld the operation platform to select this support mode, which is convenient to place and move. However, it is very important to determine the support The length of the leg, in other words, is the degree from the bottom valve to the ground. The length of the outrigger is generally about 500mm, but the length you need should be determined according to your specific use, such as how to receive the material and what kind of container to receive the material.
不銹鋼儲酒罐的正確使用方法介紹：
How to use stainless steel wine tank correctly
1） 校正pH電極和溶氧電極。
1) Adjust pH electrode and dissolved oxygen electrode.
2) 不銹鋼儲酒罐用罐體。根據需要將培養基配入罐體，按要求封裝后，小型不銹鋼儲酒罐（5L）可將罐體放入大**鍋**（115℃，30分鐘）；大型不銹鋼儲酒罐（10L及以上）采用蒸汽**（121℃，30min）。
2) Stainless steel wine tank body. The culture medium is added into the tank according to the requirements. After being packaged according to the requirements, the small stainless steel wine storage tank (5L) can put the tank body into the large * * pot * * (115 ℃, 30 minutes); the large stainless steel wine storage tank (10L and above) adopts steam * * (121 ℃, 30min).
3) 待不銹鋼儲酒罐的罐體冷卻后，將其置于臺上，安裝完成；打開冷卻水，打開氣泵電源，連接通氣管道開始通氣，調節進氣旋鈕使通氣量適當,使罐壓保持在0.05MPa；設置溫度、pH、攪拌速度等，并在確定的轉速和通氣量下對溶氧電極進行斜率標定，數值為100
3) After the tank body of the stainless steel wine storage tank is cooled, put it on the stage and complete the installation; turn on the cooling water, turn on the power supply of the air pump, connect the ventilation pipe to start ventilation, adjust the air intake knob to make the ventilation volume appropriate, and keep the tank pressure at 0.05Mpa; set the temperature, pH, stirring speed, etc., and calibrate the slope of dissolved oxygen electrode under the determined speed and ventilation rate, the value is 100
4) 待溫度穩定，各項參數都正確后，將預搖的種子接入，開始，并開始記錄各種參數。
4) When the temperature is stable and all parameters are correct, connect the pre shaken seeds, start timing, and start recording various parameters.
5) 完畢后清洗罐體和電極，將pH電極插入有3M氯化鉀的三角瓶中待用，溶氧電極的探頭用保護套，保存?zhèn)溆谩?/div>
5) After that, clean the tank and electrode, insert the pH electrode into the triangular flask with 3M potassium chloride for use, and the probe of dissolved oxygen electrode shall be protected with protective sleeve for standby.
